Features:

  1. Suitable for narrow space
  2. Rapid response time
  3. Flexible for easy assembly
  4. Elastic and solder easily
  5. RoHS Compliance
  6. UL1434 Certification


Technical Range:

Temperature ranges -50°C ~ 90°C
Resistance range at 25°C 10㏀ ~ 100㏀
Resistance Tolerances ±1%, ±3%, ±5%
Dissipation constant 0.7mW/°C (in air)
Thermal time constant 2 sec. (in air)


Application:

  1. Battery pack
  2. Printer
  3. Medical devices
  4. Heat dissipation modules
  5. Fan speed controls
  6. Surface temperature sensors
  7. High sensitivity air temperature sensors
  8. Mobile devices
  9. LCDs
  10. IT devices
